| Category | specifications | Data parameters |
| Appearance structure | Dimensions (L x D x H) | 900 * 900 *1975mm |
| Weight | 480kg |
| Length of charging cable | 5m |
| Connectors | CCS1 || CCS2 || CHAdeMO || GBT Three Guns * Four Guns |
| Electrical indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input frequency | 50/60Hz |
| Output Voltage | 200 - 1000VDC |
| Output current | 0 to 800A |
| rated power | 60-240kW |
| Efficiency | ≥94% at nominal output power |
| Power factor | >0.98 |
| Communication protocol | OCPP 1.6J |
| Functional design | Display | 7’’ LCD with touch screen |
| RFID system | ISO/IEC 14443A/B |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) |
| Communication | Ethernet – Standard || 3G/4G Modem (Optional) |
| Power Electronics Cooling | Air Cooled |
| Work environment | Operating temperature | -30 °C to 55°C |
| Working || Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) |
| Altitude | < 2000m |
| Ingress Protection | IP54 || IK10 |
| Safety design | Safety standard | GB/T,CCS2,CCS1,CHAdeMo,NACS |
| Safety protection | Overvoltage protection, lightning protection, overcurrent protection, leakage protection, waterproof protection, etc |
| Emergency Stop | Emergency Stop Button Disables Output Power |
