| Category | specifications | Data parameters |
| Appearance structure | Dimensions (L x D x H) | 600mm x 470mm x 100mm (Shell size) 740mm x 665mm x 230mm (Packing size) |
| Weight | 40kg |
| Length of charging cable | 3.5m |
| Connectors | CCS1 || CCS2 || CHAdeMO || GBT Single gun |
| Electrical indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input frequency | 50/60Hz |
| Output Voltage | 200 - 750VDC |
| Output current | 80A |
| rated power | 20 - 30kW |
| Efficiency | ≥94% at nominal output power |
| Power factor | >0.98 |
| Communication protocol | OCPP 1.6J |
| functional design | Display | No |
| RFID system | ISO/IEC 14443A/B |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) |
| Communication | Ethernet – Standard || 3G/4G Modem (Optional) |
| Power Electronics Cooling | Air Cooled |
| work environment | Operating temperature | -30°C to 75°C |
| Working || Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) |
| Altitude | < 2000m |
| Ingress Protection | IP30 |
| safety design | Safety standard | GB/T,CCS2,CCS1,CHAdeMo,NACS |
| Safety protection | Overvoltage protection, lightning protection, overcurrent protection,leakage protection, waterproof protection, etc |
