| Category | specifications | Data parameters |
| Appearance structure | Dimensions (L x D x H) | 1900mm x900mm x 1950mm |
| Weight | 750kg |
| Maximum carrying capacity | 6 dual gun charging stations or 12 single gun charging stations |
| Electrical indicators | Parallel Charge Mode(Optional) | 40 kW per Port |
| Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input frequency | 50/60Hz |
| Output Voltage | 200 - 1000VDC |
| Output current | 0 to 1200A |
| rated power | 960kW |
| Efficiency | ≥94% at nominal output power |
| Power factor | >0.98 |
| Communication protocol | OCPP 1.6J |
| Functional design | Display | Customize according to requirements |
| Communication | Ethernet – Standard || 3G/4G Modem (Optional) |
| Power Electronics Cooling | Air Cooled |
| Work environment | Operating temperature | -30℃ to 55℃ |
| Working || Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) |
| Ingress Protection | IP54 || IK10 |
| Altitude | <2000m |
| Safety design | Safety standard | GB/T,CCS2,CCS1,CHAdeMo,NACS |
| Safety protection | Overvoltage protection, lightning protection, overcurrent protection,leakage protection, waterproof protection, etc |
