Product Description:
The wall-mounted 7KW AC charger is a charging device designed for home users. The 7KW charging power is able to meet the daily home charging needs without overburdening the home power grid, making the charging post both economical and practical. The wall-mounted 7KW charger is wall-mounted and can be easily installed in a home garage, car park or on an outdoor wall, saving space and making charging more convenient. The wall-mounted AC charger's wall-mounted design allows the charger to be easily installed in home garages or car parks, eliminating the need for users to search for public charging posts or wait in queues for charging. The chargers are usually equipped with intelligent control functions, which can automatically recognise the battery status and charging demand of the EV, and intelligently adjust the charging parameters according to this information to ensure the safety and efficiency of the charging process. In summary, the wall-mounted 7KW AC charger has become an ideal choice for home users to charge with its moderate power, convenient wall-mounted design, intelligent control, high safety and convenience.
Product Parameters：
| 7KW AC Single port (wall-mounted and floor-mounted) charging pile | ||
| Equipment Models | BHAC-7KW | |
| Technical parameters | ||
| AC input | Voltage range (V) | 220±15% |
|
| Frequency range (Hz) | 45~66 |
| AC output | Voltage range (V) | 220 |
|
| Output Power (KW) | 7 |
|
| Maximum current (A) | 32 |
|
| Charging interface | 1 |
| Configure Protection Information | Operation Instruction | Power,Charge,Fault |
|
| Man-machine display | No/4.3-inch display |
|
| Charging operation | Swipe the card or scan the code |
|
| Metering mode | Hourly rate |
|
| Communication | Ethernet(Standard Communication Protocol) |
|
| Heat dissipation control | Natural Cooling |
|
| Protection level | IP65 |
|
| Leakage protection(mA) | 30 |
| Equipment Other Information | Reliability (MTBF) | 50000 |
|
| Size (W*D*H) mm | 270*110*1365 (Landing)270*110*400 (Wall mounted) |
|
| Installation mode | Landing type Wall mounted type |
|
| Routing mode | Up (down) into line |
| Worksing Environment | Altitude (m) | ≤2000 |
|
| Operating temperature(℃) | -20~50 |
|
| Storage temperature(℃) | -40~70 |
|
| Average relative humidity | 5%~95% |
| Optional | O4GWireless CommunicationO Charging gun 5m O Floor mounting bracket | |
Product Feature：
Application：
Home charging: AC charging posts are used in residential homes to provide AC power to electric vehicles that have on-board chargers.
Commercial car parks: AC charging posts can be installed in commercial car parks to provide charging for electric vehicles that come to park.
Public Charging Stations: Public charging piles are installed in public places, bus stops and motorway service areas to provide charging services for electric vehicles.
Charging Pile Operators: Charging pile operators can install AC charging piles in urban public areas, shopping malls, hotels, etc. to provide convenient charging services for EV users.
Scenic spots: Installing charging piles in scenic spots can facilitate tourists to charge electric vehicles and improve their travelling experience and satisfaction.
